Woodworking laminating wood plywood txias xovxwm tshuab
Siab nias zoo: nws tuaj yeem ua rau txoj kev sib khi ntawm txhua txheej ntawm cov plywood ntau cov tsis xws li cov kua nplaum, thiab txhim kho qhov zoo tag nrho thiab lub zog ntawm pawg thawj coj saib.
Zoo flatness ntawm cov xovxwm phaj: tom qab ua tiav cov xovxwm phaj, lub tiaj tiaj tiaj, lub tiaj tiaj tau zoo, thiab cov khoom siv tau zoo, uas yog qhov ua kom zoo rau kev ua tiav thiab siv.
Siab Stability: Lub system hydraulic tuaj yeem muab cov siab ruaj khov raws li yuav tsum tau tsis hloov pauv thaum lub sijhawm nias tus mob khaub thuas kom ntseeg tau tias cov khoom lag luam txias.
Kev lag luam yooj yim: Nruab nrog kev tswj hluav taws xob, tuaj yeem paub lub zog tsis siv neeg, txo cov siab ua haujlwm, txo cov kev siv zog ua haujlwm, txo qis kev siv zog, txhim kho ntau lawm.
Cov khoom lag luam
|
Nominal tag nrho cov siab |
5000 kn |
|
Kev Taw Qhia Ntawm Pub Phaj |
Tav toj |
|
Max qhib |
1600㎜ |
|
Dimension ntawm cov ua haujlwm |
2700×1400㎜ |
|
Txoj kab uas hla ntawm lub tog raj kheej |
Φ360㎜ |
|
Cov lej ntawm Lub Tog Raj Kheej |
2pcs |
|
Sab Laj Pab Lub Tog Raj Kheej |
Φ80㎜x2 |
|
Kev pressurization |
Tsawg dua los yog sib npaug rau 25 MPa |
|
NCO NTAWM KHEEJ KHEEJ |
1000㎜ |
|
Txoj haujlwm ntawm lub tog raj kheej |
Ntxeev |
|
Siab ntawm chav tsev phaj dawb paug |
15 KGF / ㎝2 |
|
Qhov loj me ntawm lub rooj tsavxwm |
2560×1280㎜ |
|
Tso cai siab |
Tsawg dua los yog sib npaug rau 25 MPa |
|
Hwjchim |
14Kw |
|
Qho hnyav |
Kwv yees 18000 kg |
|
Zuag qhia tag nrho |
Txog 3600 × 1380 × 3750 hli |
|
Txoj Kev Tswj Xyuas |
Tsis Siv Neeg Twj Tso Kua Muag |
|
Tuab ntawm cov sab saud thiab qis dua |
900 hli |
|
Thickness ntawm steel phaj |
40 hli |
|
Thickness ntawm accTive crossbeam |
400 HLI |
|
Thickness ntawm steel phaj |
22 hli |
|
Nrog cov saw hlau tranport ntaus ntawv |
Xaiv |
